- 40 fixtures, with maximum of 48 channels + dimmers (Total max 512 channels)
- Add Pan/Tilt shape effects with timing effects
- Add any effect to a single channel including timing effects
- Up to 10 manual override scenes during playback on faders
- Pitch fader increases or decreases show speed by up to 5 times
- Freeze button
- Master fader to adjust general light intensity
- 4 programmable custom buttons.
- Assign different frequencies of the music as a trigger for any parameter of the fixture(s).
- Export, backup or import shows via USB to PC.
SPECIFICATIONS
PHYSICALLength: 483 mmWidth: 265 mmHeight: 120 mmWeight: 4.7 kg
CONTROL AND PROGRAMMINGUp to 160 cues (1 background scene + 4 simultaneous sequences per cue): Up to 160 cuelists (automated shows with go, chase and wait functionality): Up to 160 presets on all channels: 40 fixtures of max. 40 channels (total max. 512 physical channels): 20 dimmers of max. 48 channels (total max. 512 physical channels): Effect generator with adjustable speed, swing and delay: 16-bit fan control on all channels to create spread-outs: Relative and absolute control possible over all channels: 16-bit control possible on all channels: UP to 6 sequences can be cross-faded with cues during playback: Effect macros (several factory-loaded): Auto-start of automated shows with lamp-on feature: Built-in Martin fixture library (other libraries can be uploaded via USB): Library editor to create custom fixture definitions: Export/import shows and libraries via USB to PC: Sequence trigger options: Internal clock, manual, audio (4-band, adjustable levels), BPM (with record mode)Sequence options: Forward, backward, bounce, random, one-shot freeze, one-shot releaseProtocol: DMX512
CONTROL/USER INTERFACEBlue backlit LCD display, 2 x 40 characters, to show fader labels (parameters and values): Blue backlit LCD display, 4 x 20 characters, to show menus and dialogs: 6 x faders and flash buttons for parameter control and direct access scenes during playback: Master fader: Master flash button: Blackout button: Dim button for direct access to dimmer channels: Fix button to control fixtures: Freeze button: Cue button to launch single cues: Cuelist button to activate cuelists: Programmable smoke, strobe, extra 1 and extra 2 buttons: Soft power button with 2-second switch-off protection: Pitch fader with center indent for instant playback speed adjustment: 8 x soft buttons to select items in the display: ESC and ENTER buttons for menu and dialog control: 8 x page buttons to select cue pages and fixture groups: Previous and next buttons for single-stepping, data entry, navigation: 20 x general-purpose buttons to select cues, select fixtures and enter data: Shift key to access secondary functions: Jog wheel to scroll through lists and input data: Joystick for pan/tilt control with built-in coarse/fine toggle button: Pan and tilt exclude buttons: Home button to send all selected fixtures to home positions:
INSTALLATIONTable or 19-inch rack (6U) mount:
CONNECTIONSDMX in: 5-pin locking XLRDMX out: 3-pin and 5-pin locking XLRMIDI in/out/thru: Standard MIDI (5-pin DIN)Audio trigger signal in: 6.3mm (1/4-inch) mono jackAudio trigger signal level: Line levelPC/uploader: USBDesk lamp: USBI2C expansion port: 5-pin DINAC power input: 3-pin IEC
ELECTRICALAC power: 100-240 V nominal, 50/60 Hz
APPROVALSUS safety: UL 6500Canadian safety: CAN/CSA E60065-00EU safety: EN 60950EU EMC: EN 55103-1, EN 55103-2CB Approval: IEC 60065
